Design Kits

Thank you for your interest in our Design Kits

Quantic Eulex has a number of design kits in stock or on short lead time for qualified customers. Please click on the "Sample Request" button and fill out the form. We will be in contact with you shortly.


XG-KIT-50V-01

Capacitance Values (pF):
0201 - 30, 82
0402 - 0.5, 0.7, 1.0, 1.5, 2.0, 10, 30, 82, 180, 1000
0603 - 2000


XQ-0402-200V-01

Capacitance Values (pF):
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7,
0.8, 0.9, 1.0, 1.2, 1.5, 1.8, 2.0

XQ-0402-200V-02

Capacitance Values (pF):
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7,
3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

XQ-0402-200V-03

Capacitance Values (pF):
10, 12, 15, 18, 20, 22, 24,
27, 30, 33

XQ-0603-250V-01

Capacitance Values (pF):
0.3, 0.5, 0.8, 1.0, 1.2, 1.5, 2.2, 2.7,
3.3, 3.6, 3.9, 4.7, 5.6, 6.8, 8.2, 10

XQ-0603-250V-02

Capacitance Values (pF):
10, 12, 15, 18, 20, 24, 27, 33,
39, 47, 68, 82, 100

XQ-0505-250V-01

Capacitance Values (pF):
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0,
3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

XQ-0505-250V-02

Capacitance Values (pF):
10, 12, 15, 18, 20, 22, 24, 27, 30, 33,
39, 47, 68, 82, 100

XQ-1111-500V-01

Capacitance Values (pF):
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0,
3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

XQ-1111-500V-02

Capacitance Values (pF):
10, 12, 15, 18, 20, 22, 24, 27, 30,
33, 39, 47, 56, 68, 82, 100

XQ-1111-500V-03

Capacitance Values (pF):
100, 120, 150, 180, 200, 220, 240, 270, 300,
330, 390, 470, 560, 680, 820, 1000

XQ-0603-250V-F150-01

Capacitance Values (pF):
0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.2, 1.5,
1.8, 2.2, 2.7, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2

XQ-0603-250V-F150-02

Capacitance Values (pF):
10, 12, 15, 18, 20, 22, 24, 27, 30,
33, 39, 47, 56, 68, 82
